Classical Wrapped V-Belt A B C

Classical Wrapped V-Belt is specially designed for industrial drives.
Available Types: Z, A, B, C, D, E
Standard: ISO 4184 / BS 3790
Available Grades: Normal
Other Names: Normal V-Belt, Classical Belt
Send E-mailGet Price

Cross-Sectional Sizes:

Section Top Width(mm) Thickness(mm) Angle(Degree)
Z/O/M 10.0 6.0 40
A 13.0 8.0 40
B 17.0 11.0 40
C 22.0 14.0 40
D 32.0 19.0 40
E 38.0 23.0 40



Features:

  • Anti-static,heat-resistant,wear-resistant;
    High strength;
    Low elongation;
    Small matching tolerance;
    Good abrasion resistance;
    With little generation of powder;
    Providing clean power transmission;
    High transmission efficiency under the operating.

Application:

  • Industrial drives such as pumps, generators, ball-mills, crushers, compressors etc.
